OMF11

Time:2018-06-19


OMF11
Filter By Gauge (micron): 800~600
Filter By Finish: polished,Polished
Filter By Color: Clear

Physical Parameters

Item

Property

Value

Unit

Test Method

Physical

Density

1.2

g/cm3

ISO 1183

Haze

<0.5

%

ASTM D1003

Light   Transmission

89

%

ASTM D1003

Mechanical

Tensile   Strength

60

MPa

ISO 527

Elongation

>100

%

ISO 527

Bend   Strength

91

MPa

ISO 178

Tensile   Modulus

2300

MPa

ISO 178

Surface   tension

34

 dyncm

Test fluid

Electrical

Dielectric   Constant

3

-

IEC60250

Resistant   Puncture Voltage

30

MV/mm

IEC 60243

Surface   resistivity

1.00E+16

Ω/square

IEC 60093

Volume   resistivity

1.00E+17

Ω-cm

IEC 60093

Thermal

Coefficient   of Thermal Expansion

5.8

×10-5/

ISO 11359

Thermal   Conductivity Rate

0.2

W/(m*K)

ASTM D5470

Thermal   Shrinkage

0.50.7

%

ASTM D1204

Tg

152

ISO306

Flammability

Grade of   resistant flame

V-0

           E249605

Tip: This test data is for reference only, not as an absolute application index


Certification

Product Application


Dimensions


PC Sheet

Model

 size of metric system

 size of british system

 Packing Standard

Thickness
mm

Width×Length
mm×mm

 Thickness
inch

 Width×Length
foot×foot


0.80

915×1220

0.0315″

3′×4′


915×1830

3′×6′

1000×2000

3.3′×6.6′

1220×1830

4′×6′

1220×2440

4′×8′

1.00

915×1220

0.0400″

3′×4′

915×1830

3′×6′

1000×2000

3.3′×6.6′

1220×1830

4′×6′

1220×2440

4′×8′

1.50

915×1220

0.0600″

3′×4′

915×1830

3′×6′

1000×2000

3.3′×6.6′

1220×1830

4′×6′

1220×2440

4′×8′

2.00

915×1220

0.0800″

3′×4′

1220×2440

4′×8′

2.50

915×1220

0.1000″

3′×4′

1220×2440

4′×8′

3.00

915×1220

0.1200″

3′×4′

1220×2440

4′×8′

4.00

915×1220

0.1600″

3′×4′

1220×2440

4′×8′



MSDS
