T32F

Time:2018-06-19


T32F
Filter By Gauge (micron): 35,50,75,175,200,375,500
Filter By Finish: Matte,Velvet
Filter By Color: semi-transparent

Physical Parameters

Item

Property

Value

Unit

Test   Method

Physical

Density

1.2

g/cm3

ISO 1183

Haze

78±5

%

ASTM D1003

Light Transmission

>87

%

ASTM D1003

Mechanical

Tensile Strength

60

MPa

ISO 527

Elongation

>100

%

ISO 527

Bend Strength

91

MPa

ISO 178

Tensile Modulus

2300

MPa

ISO 178

Surface tension

34

Dyn/cm

Test fluid

Electrical

Dielectric Constant

3

-

IEC60250

Resistant Puncture   Voltage

30

KV/mm

IEC 60243

Surface resistivity

1.00E+16

Ω/square

IEC 60093

Volume resistivity

1.00E+17

Ω-cm

IEC 60093

Thermal

Coefficient of   Thermal Expansion

5.8

×10-5/

ISO 11359

Thermal   Conductivity Rate

0.2

W/(m*K)

ASTM D5470

Thermal shrinkage150

0.5~0.7

%

ASTM D1204

Tg

152

ISO306

Flammability

Grade of resistant   flame

V-2/VTM-2

              UL94

Tip: This test data is for reference only, not as an absolute application index


Certification

Product Application


Dimensions

Polycarbonate Film

Model

size of metric system

size of british system

Packing Standard

 Thickness
mm

Width×Length
mm×m

Thickness
inch

Width×Length
foot×foot

omay -T32F

0.125

930×640.5

0.005″

3′×2100

Roll

1220×640.5

4′×2100

0.175

930×457.5

0.007″

3′×1500

1220×457.5

4′×1500

0.250

930×327.8

0.010″

3′×1075

1220×327.8

4′×1075

0.375

930×228.75

0.015″

3′×750

1220×228.75

4′×750

0.500

930×175.4

0.020″

3′×575

1220×175.4

4′×575




MSDS
